Intelligent Solutions for the Food & Beverage Industry
The future of the Food and Beverage industry lies in smart factories that maximize efficiency, flexibility, quality, and sustainability. Nilfisk FOOD’s Automatic Hybrid 7 Mainstation and Satellite systems are designed to help achieve these goals.
Hybrid 7 Mainstation: Best-in-Class Automation
The Hybrid 7 Mainstation is a top-of-the-line, fully automated cleaning solution tailored specifically for the F&B and OEM sectors. It offers advanced features for optimal performance and is designed for easy maintenance, with numerous smart and simplified functionalities. Its modular design ensures seamless integration, as the same components are used across the entire product range.
Customizable Foamatic Units for Versatile Cleaning
Hybrid 7 Foamatic units can be easily customized to suit specific cleaning tasks. The standard unit includes a 300-liter injector, with other sizes available to meet different needs. The unit features 16 input/output connections, expandable to a maximum of 48 I/Os, ensuring adaptability for a wide range of operations.
Nozzle bars are to be carefully selected so it’s size and amount will match the cleaning equipment’s capacity and the design of the cleaning zone. Perfect match will result in the best foam quality and the best technically possible cleaning and hygienic results.
The new norm
At Nilfisk FOOD we take pride in being a pioneer and trendsetter within the world of industrial hygiene. Therefore, we are proud to introduce a new cutting-edge technology – the Hybrid 7 – to help food and beverage producers be more productive and competitive.
Hybrid 7 – THE NEW NORM of foam cleaning
OPTIMIZED F&B and OEM
Science-based advancements allowed us to test and introduce new polymeric materials, that significantly reduces scaling on injectors and chemical non return valves, and are optimized for corrosion. The Hybrid 7 inverter is 100% optimized for connectivity.
- Lower energy consumption in stand by mode
- I/O module – 16 inputs/16 outputs
- I/O upgrade up to 3X I/O module
- Up to 100 cleaning steps
- Programmable on PC or directly on display
- Significantly reduced scaling in hard water areas
- Decreased risk of corrosion
GUIDED SERVICE
By embracing guided service, we are guiding our distributors step by step through the process of servicing the Nilfisk FOOD equipment, with a purpose to maximize performance, minimize downtime and minimize cost.
- 29% component reduction on manual block
- Clamp connected pumps
- Simplified user interface
- Simplified error log reading on display
- Intuitive programming of washing steps
MODULARITY
Hybrid 7 Inverter, Multicontroller, and block used on this Mainstations, is also used across all Nilfisk FOOD portfolio making the service easier, faster and cost effective. With the new Hybrid 7 inverter, you can run one worldwide model/voltage 380 to 528 Vac 50/60Hz.
CONNECTIVITY
Advancement on electronics like Inverter, Multicontroller and Display, gives you an overview in the Hybrid 7 app of all cleaning machines operating worldwide at your company. You can also collect information on energy consumption, water temperature and cleaning time.
REMOTE SUPPORT
Remote support function, allow technicians to connect directly to your equipment, help troubleshoot, solve problems quickly and minimize equipment downtime.
SUSTAINABILITY
Hybrid 7 inverters save approx. 70% of energy, especially when the equipment is in standby mode. Moreover, you can save approx. 47% of water and 46% of detergent, and the cleaning will be done approx. 55% faster, so you also can extend your uptime.
SAVINGS
Hybrid 7 enables the F&B producers to make significant economical savings when cleaning, while achieving better level of cleaning efficiency, supporting sustainability, and maximizing production uptime.
Documents
Directions for use Hybrid 7 MA & SA (DK, UK, DE, FR, ES, IT, PL, NL, NO, SE, FI, GR, PT) 110009190K
Spare part list 110009190
Addendum US cert. kit for BF8, SA, MA, MH
Directions for use Hybrid SA 110004669ZF
Product sheet
User guide 110009191
Software manual Hybrid 7 Display 110009737D (MH42, BH4, BH7, MP42, BP4, BF8, BF16, BF24, BF32, Foamatic mainstation and satellite)
Software manual 110009192C- old display
IO module manual 110009305B
Software change log Hybrid 7 Inverter
Service check list
Recommended spare part list Hybrid 7 Foamatic mainstation
Software
NEW!! – Hybrid 7 Software (Boot.bin + updpack.bin) v2.2.1
Last updated 25 days ago.
Notes:
It is very important to copy these 2 files to a USB flash drive before any update is carried out!
Change log:
| Version | Changes | Released |
|---|---|---|
| 2.2.1 | New layout in GUI start and Info menu, tank control setup improved, error text updated, Properties for add/remove IO, Foamatic overview new design. Improved navigation when scrolling sideways, Improved input/output config., wash progrom checked for correct Foamatic type gives a GUI warning if different. | 20250403 |
| 2.2.0 | New layout in GUI start and Info menu, tank control setup improved, error text updated, Properties for add/remove IO, Foamatic overview new design. Improved navigation when scrolling sideways, Improved input/output config., wash progrom checked for correct Foamatic type gives a GUI warning if different. | 20250402 |
| 2.1.5 | User buttons with icons, fixed pause/start wash program in manual mode, Foamatic OEM mode waiting for high pulse for activation after start up pressure to text corrected temporary pressure to text/2, Multi booster readings menu improved, boundary check for inverter input/output value improved | 20241111 |
| 2.1.3 | MX unit added, new firmware upgrade handling with packet update, many improvements, and bugs fixed, Fixed saved input/output config of multi booster, Fixed set all input/output ports when set to a multibooster | 20241015 |
Foamatic TOOL v1.2.0
Last updated 0 days ago.
Notes:
Hybrid 7 Foamatic MA & SA
Change log:
| Version | Changes | Released |
|---|---|---|
| 1.2.0 | • Bug fixing | |
| 1.2.0 | • Uploard and download of wash programs using the WIFI AP (access point) | |
| 1.1.0 | • Upload Wash Programs directly to the Foamatic using the machine Access Point (WIFI) | |
| 1.0.1 | • Added cancel button to wash steps | |
| • Changed "remove room" to "remove area" in the wash program step | ||
| • In Select machine screen add next to "product a with level indicator" the product alias if is selected | ||
| • Fix the bug where you can add more wash steps than possible | ||
| • When editing the wash step, the action pause, the time does not show up when uploading a setup file | ||
| 1.0.0 | • Bug Fixes: We've tackled various bugs to enhance your app experience. | |
| • Unit System Options: Easily toggle between Imperial and Metric measurement systems, customizing the app's units to suit your preference. | ||
| • Bug Fixes: We've tackled various bugs to enhance your app experience. |
Hybrid 7 Inverter Upgrade Tool Software v1.0.0
Last updated 0 days ago.
Notes:
Valid for the following models:
Hybrid 7 Mainstations MH42, MP42,
Hybrid 7 Multi Booster BF16, BF24, BF32
Hybri 7 Booster floor BF4, BF8,
Hybrid 7 Booster wall BH4, BP4, BH7,
Hybrid 7 Foamatic MA & SA
Change log:
| Version | Changes | Released |
|---|---|---|
| 1.0.0 |
Hybrid 7 Inverter Software v2.12
Last updated 1 years, 6 months, 23 days ago.
Notes:
Valid for the following models:
Hybrid 7 Mainstations MH42, MP42,
Hybrid 7 Multi Booster BF16, BF24, BF32
Hybri 7 Booster floor BF4, BF8,
Hybrid 7 Booster wall BH4, BP4, BH7,
Hybrid 7 Foamatic MA & SA
Change log:
| Version | Changes | Released |
|---|---|---|
| 2.12 | Delayed start improved: Error output reacts on display errors | 20231005 |
| 2.11 | Changes to bootloader | 20231005 |
| 2.10 | Initial version | 20231002 |
Videos
How to service Hybrid 7 block (manual block)
Hybrid 7 Foamatic block (automatic block)
How to service Hybrid Foamatic block (automatic block)
Nilfisk FOOD Case study - Automated cleaning equipment
Automatic Cleaning
Automatic Cleaning Nilfisk FOOD
Automated cleaning by Nilfisk FOOD
How to remove injector
How to service injector and non return valves
Tips & Tricks when changing a water pump
How to connect to Hybrid 7 via wifi hotspot
Gallery
Available models
| Model | Description | Item Number | EBS no. |
|---|---|---|---|
| MA2IM-300L | Hybrid 7 Foamatic Mainstation 2 products, interface, manual outlet | 110009153 | 10059603 |
| MA3IM-300L | Hybrid 7 Foamatic Mainstation 3 products, interface, manual outlet | 110009154 | 10059602 |
| MA2I-300L | Hybrid 7 Foamatic Mainstation 2 products, interface | 110009151 | 10059599 |
| MA3I-300L | Hybrid 7 Foamatic Mainstation 3 products, interface | 110009152 | 10059598 |
| SA2IM-300L | Hybrid 7 Foamatic Satellite 2 products, interface, manual outlet | 110009157 | 10059597 |
| SA3IM-300L | Hybrid 7 Foamatic Satellite 3 products, interface, manual outlet | 110009158 | 10059596 |
| SA2I-300L | Hybrid 7 Foamatic Satellite 2 products, interface | 110009155 | 10059601 |
| SA3I-300L | Hybrid 7 Foamatic Satellite 3 products, interface | 110009156 | 10059600 |
| MA2M-300L | Hybrid 7 Foamatic Mainstation 2 products, manual outlet | 110009432 | 10059594 |
| MA3M-300L | Hybrid 7 Foamatic Mainstation 3 products, manual outlet | 110009433 | 10059592 |
| MA2-300L | Hybrid 7 Foamatic Mainstation 2 products | 110009430 | 10059595 |
| MA3-300L | Hybrid 7 Foamatic Mainstation 3 products | 110009431 | 10059593 |
| SA2M-300L | Hybrid Foamatic Satellite 2 products, manual outlet (not Hybrid 7) | 110004314 | 10039537 |
| SA3M-300L | Hybrid Foamatic Satellite 3 products, manual outlet (not Hybrid 7) | 110004316 | 10039541 |
| SA2-300L | Hybrid Foamatic Satellite 2 products (not Hybrid 7) | 110004310 | 10039528 |
| SA3-300L | Hybrid Foamatic Satellite 3 products (not Hybrid 7) | 110004312 | 10039533 |
